The Analog Discovery Studio Max – New
The Analog Discovery Studio Max (ADS Max) is a comprehensive electronics laboratory solution designed for academic instruction and hands-on learning. Equipped with 14 built-in instruments, supporting everything from a multimeter and bode plots to digital protocol generation and analysis, the ADS Max is ideal for circuit design, signal analysis, and embedded systems coursework. With a variety of removable and curriculum-tailored Canvas boards to enhance its functionality, the ADS Max enables dynamic, hands-on experiences in both classroom and remote learning environments.
- All-in-One Design: Combines 14 essential test instruments, including an oscilloscope, waveform generator, and logic analyzer. Ideal for both in-classroom and remote learning environments.
- ADS Max Ecosystem: Extends the platform with subject-specific materials and hardware from academic partners.
- Breadboardable Interface: Allows for easy and quick circuit design and testing.
- Software Support: Compatible with Digilent WaveForms, LabVIEW, C, and Python for custom software development.
The Analog Discovery Studio Max Overview
02
TEST DEVICES
Essential Instruments
All Digilent test and measurement devices are multi-instrument electronics tools designed to bring the benchtop to you. Digilent’s portable USB scopes, logic analyzers and signal generators allow you to measure, visualize, generate, record, and control mixed-signal circuits of all kinds.
Combined with our free WaveForms software, detailed documentation, and a dedicated support community, our test and measurement hardware will turn your computer into a multi-instrument circuit analysis tool, all without the physical constraints of a lab.
03
TEST DEVICES
Analog Discovery Pro Line
Despite Digilent’s origin in education, there is a growing demand for products that provide flexibility along with more robust capabilities that professional applications need.
Digilent’s Analog Discovery Pro line gives engineers the ability to tap into the efficiency of the WaveForms software while offering a wider selection of specifications in products created with the professional in mind.
04
TEST DEVICES
Accessories
The Accessories for Digilent test and measurement products have been selected to support a wide variety of applications and testing scenarios.
The breadboards, power supplies, DMM, cables, probes, clips and parts kits have all been tested and vetted by our engineers to ensure compatibility with our devices.
05
DİGİLENT
FGGA Board
For over two decades, Digilent has proudly worked with Xilinx to become a global leader in the design and manufacturing of cost-optimized field-programmable gate array (FPGA) and System on a Chip (SoC) development boards.
Optimized for accessibility and flexibility, our control system boards are suited to a wide array of applications ranging from embedded vison and sensor fusion to networking and RF to embedded measurement and control systems. Enjoy high performance-to-price ratio, ease-of-use through onboard peripheral support, extensive documentation and example designs, and an open-source philosophy.
06
TEST DEVICES
DAQ & Data Loggers
Measurement Computing Corporation (MCC) and Data Translation (DT) DAQ products are now part of the Digilent family of test and measurement solutions.
MCC and DT are leading suppliers of data acquisition solutions are easy-to-use, easy-to-integrate, and easy-to-support.
07
TEST DEVICES
Software
Digilent’s proprietary software solutions enable you to communicate with our system boards and a wide assortment of logic devices and use our available analog and digital test & measurement instruments.
Refined by customer feedback for years, these powerful and FREE software applications allow you to fully customize your project, from creating and modifying designs for your system board to custom scripting of instruments for capturing, recording, analyzing, and generating mixed signal and mixed domain waveforms.
