Voltaj Ürünleri

Uzaktan Erişim için Analog Çıkış Modülü

The Analog Output Module for Remote I/O features a 2-wire spring terminal connection, selectable output ranges (0 V to 10 V, ±10 V, 0 V to 5 V, ±5 V, 0 mA to 20 mA, 4 mA to 20 mA, and ±20 mA) output ranges, and short circuit proof outputs. A remote I/O system consists of an EtherCAT bus coupler and individual modules mounted on a DIN rail. You control the Analog Output Module for Remote I/O from a real‐time controller, such as a CompactRIO Controller or an Industrial Controller. You can use remote I/O hardware to add low‐cost I/O for simple tasks while your controller handles advanced tasks such as image processing, motion control, and high‐speed or specialty measurements.

C Serisi Çok Fonksiyonlu I/O Modülü

The C Series Multifunction I/O Module is a cost-effective, general-purpose I/O module that helps system designers fit more functionality into a single system. The module includes analog input, analog output, and 5 V TTL digital I/O channels. You can use the C Series Multifunction I/O Module with select APIs such as LabVIEW FPGA.

C Serisi Evrensel Analog Giriş Modülü

The C Series Universal Analog Input Module helps you perform multi-purpose measurements. This module includes built-in support for accelerometer, powered sensor, full-bridge, and voltage measurements as well as quarter-bridge, half-bridge, 60 V, and current measurements using measurement-specific adapters. You also can choose options to measure signals from sensors such as strain gages, resistance temperature detectors (RTDs), thermocouples, load cells, and other powered sensors.The C Series Universal Analog Input Module includes the NI-DAQmx driver and configuration utility that simplify configuration and measurements. NI-DAQmx supports NI programming environments as well as Python, ANSI C, C#.NET, and MathWorks MATLAB® software.

C Serisi Voltaj Giriş Modülü

The C Series Voltage Input Module helps you work with voltage measurement applications. This module features isolation to separate channels from each other, from COM, or from earth ground for safety, noise immunity, and high common-mode voltage range. The module features up to 100 V of overvoltage protection for errant signal connection or unexpected outputs to the individual channels. You can use included options such as configurable input ranges, output channels, various connectors, and enclosed or non-enclosed modules.The C Series Voltage Input Module includes the NI-DAQmx driver and configuration utility that simplify configuration and measurements. NI-DAQmx supports NI programming environments as well as Python, ANSI C, C#.NET, and MathWorks MATLAB® software.

C Serisi Voltaj Çıkış Modülü

The C Series Voltage Output Module helps you update analog output models that feature overvoltage protection, short-circuit protection, low crosstalk, fast slew rate, high relative accuracy, and NIST-traceable calibration. This module includes up to 16 channels. Some models include a channel-to-earth ground double isolation barrier for safety and noise immunity as well as improved signal quality, and some higher density models conserve chassis space, which leaves room for other measurement types.The C Series Voltage Output Module includes the NI-DAQmx driver and configuration utility that simplify configuration and measurements. NI-DAQmx supports NI programming environments as well as Python, ANSI C, C#.NET, and MathWorks MATLAB® software.

C Serisi Voltaj ve Akım Giriş Modülü

The C Series Voltage and Current Input Module features up to 16 input channels with built-in noise rejection. You can use this module to combine the two most common inputs to reduce the overall number of modules you need in your measurement system.The C Series Voltage and Current Input Module includes the NI-DAQmx driver and configuration utility that simplify configuration and measurements. NI-DAQmx supports NI programming environments as well as Python, ANSI C, C#.NET, and MathWorks MATLAB® software.

C Serisi Sayısallaştırıcı Modülü

The C Series Digitizer Module takes both high-speed and high-resolution time- and frequency-domain measurements. It features up to four channels that can sample at speeds up to 20 MS/s—ideal for discrete detection of signals 10 MHz and smaller for applications such as fault detection, partial discharge analysis, and acoustic measurements. The module's store-and-forward architecture allows up to 128 Mbits of measurement data to be sent back to the CompactRIO Controller and analyzed. You can use the module as part of a CompactRIO system and use the LabVIEW FPGA Module to develop an advanced trigger based on low-speed streaming for added flexibility. This digitizer includes the NI-DAQmx driver and configuration utility that simplifies configuration and measurements. NI-DAQmx supports NI programming environments and Python, ANSI C, C#.NET, and MathWorks MATLAB® software.

PXI Çok Fonksiyonlu I/O Modülü

The PXI Multifunction I/O Module provides I/O with varying numbers of channels, sample rates, and output rates with precise timing, triggering, and synchronization between models. This module can be used for industry applications such as laboratory research, design verification test, and manufacturing test.The PXI Multifunction I/O Module includes the NI-DAQmx driver and configuration utility that simplify configuration and measurements. NI-DAQmx supports NI programming environments as well as Python, ANSI C, C#.NET, and MathWorks MATLAB® software.

PXI Çok Fonksiyonlu Yeniden Şekillendirilebilir I/O Modülü

PXI Multifunction Reconfigurable I/O Modules feature a dedicated analog-to-digital converter (ADC) per channel for independent timing and triggering. This design offers specialized functionality such as multirate sampling and individual channel triggering, which are outside the capabilities of typical data acquisition hardware. You can customize these models with the LabVIEW FPGA Module to develop applications requiring precise timing and control such as hardware-in-the-loop (HIL) testing, custom protocol communication, sensor simulation, and high-speed control. PXI Express models also include peer-to-peer streaming for direct data transfer to other PXI Express models.

PXI Analog Giriş Modülü

The PXI Analog Output Module supports both static and software-timed voltage output applications. This module include 5 V TTL/CMOS digital I/O lines. Some models can deliver simultaneous, multichannel updates for control and waveform output applications, such as stimulus-response, power supply control, high-speed, deterministic control, and sensor/signal simulation. These advanced features help you use the PXI Analog Output Module to replace several kinds of instruments, including stand-alone proportional integral derivative (PID) controllers, low-speed arbitrary waveform generators, and function generators.The PXI Analog Output Module includes the NI-DAQmx driver and configuration utility that simplify configuration and measurements. NI-DAQmx supports NI programming environments as well as Python, ANSI C, C#.NET, and MathWorks MATLAB® software.

PXI Analog Çıkış Modülü

The PXI Analog Output Module supports both static and software-timed voltage output applications. This module include 5 V TTL/CMOS digital I/O lines. Some models can deliver simultaneous, multichannel updates for control and waveform output applications, such as stimulus-response, power supply control, high-speed, deterministic control, and sensor/signal simulation. These advanced features help you use the PXI Analog Output Module to replace several kinds of instruments, including stand-alone proportional integral derivative (PID) controllers, low-speed arbitrary waveform generators, and function generators.The PXI Analog Output Module includes the NI-DAQmx driver and configuration utility that simplify configuration and measurements. NI-DAQmx supports NI programming environments as well as Python, ANSI C, C#.NET, and MathWorks MATLAB® software.

FieldDAQ için Voltaj Giriş Cihazı

The Voltage Input Device for FieldDAQ measures up to eight ±10 V channels with 24-bit resolution and simultaneous sample rates up to 100 kS/s/ch. Some models can power sensors, such as pressure sensors, with up to 24 V per input channel. This device offers 500 V channel-to-channel isolation, protecting instrumentation from high-transient voltages. Additionally, the device is IP65 and IP67 rated to be dust-proof and water-submersible, can operate in -40 °C to 85 °C environments, and can sustain 100 g shock and 10 g vibration. It has an integrated network switch for simplified daisy chaining and provides tight synchronization over time sensitive networking (TSN) for distributed data acquisition systems.The Voltage Input Device for FieldDAQ includes the NI-DAQmx driver and configuration utility that simplify configuration and measurements. NI-DAQmx supports NI programming environments as well as Python, ANSI C, C#.NET, and MathWorks MATLAB® software.

Güç Ölçüm Koşullandırıcısı

The Power Measurements Conditioner provides voltage and current signal conditioning for a supported data acquisition module or device to make up to four simultaneous power measurements per conditioner. It also includes attenuation for voltage channels up to 2,000 V and has power, communication, and signal lines for current measurements from current transducers.

Uzaktan Erişim için Voltaj Giriş Modülü

The Voltage Input Module for Remote I/O features 2-, 3-, and 4-wire spring terminal connection methods, a built-in power supply for sensors, four selectable input ranges, and simultaneous sampling. A remote I/O system consists of an EtherCAT bus coupler and individual modules mounted on a DIN rail. You control the Voltage Input Module for Remote I/O from a real-time controller, such as a CompactRIO Controller or an Industrial Controller. You can use remote I/O hardware to add low-cost I/O for simple tasks while your controller handles advanced tasks such as image processing, motion control, and high-speed or specialty measurements.

Uzaktan Erişim için Analog Çıkış Modülü

The Analog Output Module for Remote I/O features a 2-wire spring terminal connection, selectable output ranges (0 V to 10 V, ±10 V, 0 V to 5 V, ±5 V, 0 mA to 20 mA, 4 mA to 20 mA, and ±20 mA) output ranges, and short circuit proof outputs. A remote I/O system consists of an EtherCAT bus coupler and individual modules mounted on a DIN rail. You control the Analog Output Module for Remote I/O from a real‐time controller, such as a CompactRIO Controller or an Industrial Controller. You can use remote I/O hardware to add low‐cost I/O for simple tasks while your controller handles advanced tasks such as image processing, motion control, and high‐speed or specialty measurements.

Çok Fonksiyonlu I/O Cihazı

The Multifunction I/O Device features I/O with varying channels, sample rates, output rates, and other features to meet many common measurement requirements. You can use the device for industry applications such as laboratory automation, research, and design verification. The included DAQExpress companion software provides basic measurement and analysis, while the included NI-DAQmx driver provides the ability to create customized automated measurement and control applications. NI-DAQmx supports NI programming environments as well as Python, ANSI C, C#.NET, and MathWorks MATLAB® software.

Çok Fonksiyonlu Yeniden Şekillendirilebilir I/O Cihazı

Multifunction Reconfigurable I/O Devices feature a dedicated A/D converter (ADC) per channel for independent timing and triggering. This design offers specialized functionality such as multirate sampling and individual channel triggering, which are outside the capabilities of typical DAQ hardware. You can customize these devices with the LabVIEW FPGA Module to develop applications requiring precise timing and control such as hardware-in-the-loop (HIL) testing, custom protocol communication, sensor simulation, and high-speed control.

Analog Çıkış Cihazı

The Analog Output Device helps you create applications such as stimulus-response, power supply control, deterministic control, and sensor/signal simulation. The Analog Output Device supports various output resolutions, channel counts, and other onboard features, so you can replace several kinds of instruments in your system, including stand-alone proportional integral derivative (PID) controllers, low-speed arbitrary waveform generators, and function generators.The Analog Output Device includes the NI-DAQmx driver and configuration utility that simplify configuration and measurements. NI-DAQmx supports NI programming environments as well as Python, ANSI C, C#.NET, and MathWorks MATLAB® software.
